A Kitchen That Hosts Needs a Hood That Actually Moves Air

When eight people are standing around the island and something is searing on the range, the old recirculating hood gives up in about a minute. We remodel Carlsbad kitchens around ventilation, the wiring that feeds it and the lighting you serve under.

White shaker kitchen cabinets with butcher block counters, open wood shelves and a small wall hood beside the range

From Under the Hood

Notes on smoke, airflow, wiring and light in kitchens built for company.

Why Your Kitchen Fills With Smoke Every Time You Entertain

Why Your Kitchen Fills With Smoke Every Time You Entertain

It happens at almost every dinner party in a house with an open kitchen. The first pan of steaks hits the cast iron, somebody cracks a joke about the smoke detector, and five minutes later the detector in the hallway proves them right. The hood is on. It is humming. And the haze is drifting straight past it toward the couch.

Most people assume the fan is too weak and go shopping for a bigger one. Sometimes that is part of the problem. Usually it is the smallest part. A range hood that fails in a kitchen full of guests is typically failing for four reasons at once: it is the wrong size or in the wrong position, it is connected to the wrong duct, the house cannot supply the air it is trying to remove, and the room around it has changed since it was installed.

This is how we walk through that problem in Carlsbad kitchens, and what is worth spending on.

The Kitchen Used to Be a Closed Room

A lot of the hoods we remove were installed when the kitchen had four walls and a doorway. That describes plenty of 1950s and 1960s cottages around Olde Carlsbad, and many 1980s and 1990s homes in La Costa and Calavera Hills before their owners opened them up.

In a closed kitchen, a small thirty inch hood with a light fan was tolerable. Smoke that escaped the hood stayed in the kitchen, the door was shut, a window got opened, and the rest of the house was mostly spared.

Then the wall to the family room came out. The kitchen gained an island with stools, and the island became where everyone stands. Now there is no door to close, air moves freely through a much larger space, and every person walking between the refrigerator and the patio slider creates a draft that bends the smoke plume sideways and out from under the hood. The same hood that was fine for twenty years stops working overnight, and nothing about it changed.

The first question we ask is not what hood you want. It is how the room is used when people are over.

Capture: The Hood Has to Catch the Plume

Heat and smoke rise from a cooktop in a plume that spreads as it climbs. The higher the hood, the wider that plume is by the time it gets there. A hood catches what falls inside its footprint and loses what falls outside, no matter how strong the fan is.

That gives you three levers.

Width. The hood should be at least as wide as the cooktop, and for heavy cooking it helps to go a few inches wider on each side. The most common mistake we see is a thirty inch hood over a thirty six inch range, where the two outside burners, often the big ones, sit half outside the hood.

Depth. Shallow hoods look sleek and miss the front burners. The front burners are where most of the cooking actually happens because they are easiest to reach.

Height. Manufacturers publish a mounting height range for each hood, and following it matters. Mounted at the low end, a hood catches much more. Mounted high to clear a tall cook’s head or to line up with a tile pattern, it catches less. We treat the height as a performance decision and talk through the trade-off before the backsplash is designed around it.

What About Microwave Hoods

An over-the-range microwave is a compromise hood. It is shallow, it sits high, the fan is small, and many of them are set to recirculate through a filter back into the room. In a small closed kitchen used for everyday cooking, it can be acceptable. For a kitchen where you sear, roast and stir fry for a group, it is the weakest link, and it is the first thing we suggest replacing.

Airflow: What the CFM Number Really Means

Hood fans are rated in cubic feet per minute. For a wall hood over an electric or induction cooktop, around 100 CFM per foot of cooktop width is a reasonable starting point. An island hood, which has no wall behind it to steer the plume, usually needs closer to 150 CFM per foot. For gas, a common rule is 100 CFM for every 10,000 BTU of combined burner output, which is why a large pro-style range ends up needing a lot of air.

Those are starting points, not targets. The rated number is measured under ideal conditions with very little resistance. Real installations have duct, elbows, a wall or roof cap and a backdraft damper, all of which push back against the fan.

The Duct Is Where Most Hoods Lose

This is the part homeowners never see and the part that most often explains a disappointing hood.

A fan moves air through a duct the way water moves through a hose. A narrow hose, a long hose and a kinked hose all deliver less water. The same fan on a six inch duct with a long run and three elbows might deliver only half its rating, and it gets noisy doing it because it is straining.

When we plan a duct run we look at:

  • Diameter. The duct should match or exceed the hood’s outlet size. Stepping down a size to fit through a joist bay costs real airflow.
  • Material. Smooth rigid metal duct. Flexible foil duct has ribbed walls that add turbulence, collect grease and sag.
  • Length and elbows. Each elbow behaves like several extra feet of straight duct. We look for the shortest, straightest route to the outside, which sometimes means moving the cooktop a few inches or choosing a wall cap over a roof cap.
  • Sealing. Foil tape on every joint. Cloth duct tape dries out and lets go in a warm attic within a few summers.
  • The cap and damper. A cheap cap has a small free area and a flimsy damper that sticks. Near the coast, west of the freeway, it will also corrode.

We see a lot of 1990s kitchens where the hood never actually vented outside at all. The duct stops in the cabinet above, or in the attic, or the hood was simply set to recirculate. Grease collects in the attic insulation, which is its own concern. If that is what we find, it changes the scope, and we would rather tell you at the walkthrough than during demolition.

Recirculating Hoods

A recirculating hood passes air through a grease filter and a charcoal filter and blows it back into the room. It catches some grease, and a fresh charcoal filter reduces odors. It does not remove heat, steam or the fine smoke particles that set off detectors. In a condo with no path to the outside, it may be the only option and we will install a good one. In a detached house where a duct can reach a wall or roof, we duct it.

Noise Is a Performance Problem Too

A hood loud enough to drown out conversation gets switched to low or turned off entirely the moment guests arrive. That is exactly when it is needed most.

Hood noise is rated in sones, and the ratings at high speed can be surprisingly loud. Two things help. A properly sized duct lets the fan move air without straining, which is quieter. And a remote or inline blower, mounted in the attic or on the roof instead of inside the hood, moves the motor noise away from the room. For island hoods in open great rooms, we often recommend one or the other.

Make-Up Air: The House Has to Breathe In

Every cubic foot of air a hood pushes outside has to come back into the house from somewhere. In an older cottage with leaky windows, it seeps in on its own. In a newer, tightly built house in Bressi Ranch or Robertson Ranch, it may not, and three things can happen:

  1. The hood moves far less air than it is rated for, because it is fighting negative pressure.
  2. Air gets pulled backward down a fireplace flue, or past a gas water heater or furnace vent, which can draw combustion gases into the living space.
  3. Doors whistle and slam and the house feels drafty in odd places.

Many residential codes require a make-up air system once a kitchen exhaust fan exceeds 400 CFM. That usually means a motorized damper on an outside air duct, wired to open when the hood turns on, sometimes with a way to temper the incoming air. We confirm the requirement for your house during plan review with the City of Carlsbad and design the make-up air path before a large hood is ordered. It is much harder to add after the ceiling is closed.

The Wiring Behind a Hood That Works

Ventilation work and electrical work overlap more than people expect. A large hood with an internal blower, or a remote blower plus a make-up air damper, may need its own circuit and an interlock between the two. The remodel that adds an island hood often adds an induction cooktop at the same time, and induction wants a dedicated 240 volt circuit sized to the model.

That is where the panel comes in. Before recommending a hood and cooktop together, we check the panel’s capacity and open spaces. Older homes near the Village sometimes need a service upgrade to support induction plus a second oven, and it is better to know that before the appliances are bought.

Lighting belongs in the same plan. Many modern hoods carry their own task lights, but in an entertaining kitchen we also place under-cabinet lighting along the prep runs and pendants over the island that do not block the sightline to the hood. Everything goes on separate dimmers so the room can shift from cooking to serving.

Carlsbad Conditions That Change the Answer

A few local factors come up repeatedly.

Marine layer and salt air. Homes within a few miles of the beach see damp mornings and salty air. Stainless hood bodies hold up well inside, but outside caps, dampers and fasteners corrode. We use caps built for coastal exposure and place them where they can be cleaned.

Inland heat. Further east, summer afternoons get hot, and a hood pulling hot outside air in through a make-up damper raises the question of tempering it. It is worth a conversation for anyone who cooks big dinners in August.

HOA review. Planned communities in La Costa, Aviara, Rancho Carrillo and Calavera Hills commonly have architectural review for exterior changes. A new roof jack or wall cap on a visible elevation may need approval, so we include it with the permit planning rather than discovering it later.

Roof type. Tile roofs, common across the planned communities, need careful flashing around a new penetration. A wall cap is sometimes the simpler, drier choice.

Timeline: What to Expect

For a hood replacement using an existing, properly sized duct, most of the work fits in a day or two, plus any wiring changes.

For a new duct route, island hood, make-up air and new circuits as part of a remodel, the sequence runs like this: design and appliance selection, permit submission, demolition, framing for the duct chase, ventilation and electrical rough-in, inspection, insulation and drywall, cabinets, countertop template, countertop installation, then hood, lights and trim. Cabinet lead times and inspection scheduling set the pace more than the labor does. A full remodel with this scope usually runs six to twelve weeks from demolition, and we set up a temporary kitchen elsewhere in the house for that stretch.

What Is Worth Spending On, and What Is Not

Worth it: a hood wide enough for the cooktop, mounted at the right height; a properly sized rigid duct on a short route to the outside; a coastal-rated cap; make-up air when the fan and the house require it; and a panel check before appliance shopping.

Often not worth it: the largest blower in the catalog when the duct cannot carry it; a decorative hood chosen purely for looks that sits too high to catch anything; or a panel upgrade when a load calculation shows the existing service can handle the appliance list.

If your hood already vents outside on a reasonable duct and the kitchen is not changing layout, a better hood in the same position may solve the whole problem for a fraction of a remodel. We will say so.

Before You Call

It helps to know three things: what you cook most when people are over, whether the current hood vents outside (look for a cap on the roof or an exterior wall near the kitchen), and what size the cooktop is. With those, a walkthrough goes quickly.

Call (442) 315-0648 and we will come look at the ceiling above your range, the path to the outside and your electrical panel before talking about anything else.

Read the full article

Air, Power and Light for a Kitchen Full of Guests

Six pieces of a kitchen remodel that most contractors leave to whoever shows up last.

  • Range Hood Sizing and Selection

    We size the hood to the cooktop and the cooking, not to the showroom. Width, depth, mounting height and fan airflow are chosen together so the hood captures a searing pan instead of just humming over it.

  • Duct Routing to the Outside

    Smooth rigid metal duct at the diameter the fan needs, the shortest practical path to a roof or wall cap, and as few elbows as the framing allows. Recirculating is a last resort, and we say so when it is the only honest option.

  • Make-Up Air Planning

    A powerful hood in a tight house pulls air from somewhere, sometimes down a fireplace flue or a water heater vent. We check the threshold and plan a make-up air path before you fall in love with a large blower.

  • Island and Peninsula Hoods

    An island cooktop has no wall to steer the plume, so the hood needs more overhang and more airflow than the same range on a wall. We work out the ceiling framing, duct chase and sightlines across the room.

  • Dedicated Circuits and Panel Checks

    Induction ranges, double ovens, beverage fridges and warming drawers each want their own circuit. We load-calculate the panel first, because an older cottage on a small service may need an upgrade before the appliance list makes sense.

  • Layered Kitchen Lighting

    Under-cabinet lights for prep, pendants that do not block the view to the hood, recessed cans placed off the edge of the counters, and dimmers so the room can go from cooking to dinner without a switch hunt.

What Clearing the Smoke Costs

Ventilation work is priced by how far the duct has to travel and what the walls and ceiling hide, far more than by the hood you pick. These are plain ranges for Carlsbad homes, and we explain what moves your number on the walkthrough.

Hood Swap on an Existing Duct$1,200 to $3,800
  • Duct already vents outside
  • Hood and damper replaced
  • Circuit checked and tested
Ask about a swap
Entertaining Kitchen Package$18,000 to $45,000
  • Island hood and ceiling duct chase
  • Make-up air and panel work
  • Part of a full kitchen remodel
Plan the whole room
  • Capture beats fan speedA bigger motor does not help if the hood is narrower than the cooktop or hung too high. Smoke rises in a plume that spreads as it climbs, and the hood has to be wide and low enough to catch it.
  • Duct is where hoods failA strong fan on a skinny, kinked duct run moves a fraction of its rated air and gets loud doing it. Duct diameter, length and elbow count decide what you really get.
  • Salt air eats the outside halfWest of the freeway, a cheap wall cap and damper corrode within a few years and start rattling or sticking open. The part of the system you never see is the part that has to be built for the coast.
  • Smoothedgedesign remodels kitchens in Carlsbad for people who cook for company, and we plan those kitchens from the ceiling down. Range hood capture area, duct size and route, make-up air, dedicated appliance circuits, GFCI and AFCI protection, under-cabinet lighting and panel capacity all get settled before cabinets are ordered, because every one of them changes where the boxes go and what the drywall hides. Homes in Olde Carlsbad, La Costa, Aviara and Bressi Ranch each give us a different set of problems to solve on the way.

    Most kitchens we open were built with ventilation as an afterthought. A thirty inch hood with a small fan that blows back through a charcoal filter, or a microwave hood mounted too high to catch anything, was fine when the kitchen was a closed room. Knock out the wall to the family room, add an island with a cooktop in it, invite the neighbors over for a Saturday dinner, and that same fan is pushing smoke and grease into the sofa. Guests notice the smell before they notice the new counters.

    We work in order. We look at what you actually cook and how many people are usually in the room, size the hood and the duct to that, check whether the fan crosses the make-up air threshold, confirm the panel can carry an induction range or a second oven, and draw the lighting so the island is bright enough to serve on without being glaring. Plans go to the City of Carlsbad for permits when walls, circuits or duct penetrations change, and to your HOA when a new roof or wall cap faces the street. Then demolition, rough-in, inspection, cabinets, template, counters and finish, in that order.

    Carlsbad Homes Where We Run Ductwork

    Every part of the city puts the hood and the wiring in a different position, from coastal cottages to planned communities in the hills.

    • Carlsbad, CA (92008, 92009, 92010, 92011)
    • Olde Carlsbad and the Village
    • La Costa and Rancho Carrillo
    • Aviara and Calavera Hills
    • Bressi Ranch and Robertson Ranch
    • Homes west of the freeway near the beach

    Call (442) 315-0648. If your community has an architectural committee, have the name of the management company handy for any exterior vent change.

    Hood, Duct and Circuit Questions

    How many CFM does my range hood need?
    Less than the brochures suggest, and it depends on the cooktop and the hood's position. A wall hood over an electric or induction range usually does well at around 100 CFM per foot of cooktop width, and an island hood wants closer to 150. For a gas range a common starting point is 100 CFM for every 10,000 BTU of total burner output. Past that, capture area and duct size matter more than a bigger number on the box.
    Is a recirculating hood good enough?
    It catches some grease, and its charcoal filter takes the edge off odors when it is fresh. It does nothing about heat, steam or the fine smoke that sets off detectors, because it blows all of that back into the room. In a closed galley it can get by. In an open kitchen where people gather it is the reason the house smells like dinner the next morning. We duct outside whenever the structure allows it.
    Will a bigger hood need make-up air?
    Often. Many residential codes require a make-up air path once a kitchen exhaust fan passes 400 CFM, and newer homes in Bressi Ranch or Robertson Ranch are built tight enough that a large fan will struggle or pull air backward through other vents without one. We confirm what plan check wants for your house before a hood is ordered, not after the inspector asks.
    Do I need a permit for a new hood and circuits?
    Replacing a hood on the same duct and circuit usually does not. Cutting a new hole through the roof or an exterior wall, adding circuits, relocating a gas line or moving a wall generally does, and the City of Carlsbad inspects the rough work before it is closed up. Planned communities in La Costa and Aviara may also want architectural review for a new cap on a visible elevation. We handle both submissions.
    How long will we be without a kitchen?
    For a hood and duct replacement on its own, usually two to four days. When ventilation and wiring are part of a full remodel, plan on six to twelve weeks of disruption, driven mostly by cabinet lead times, inspection scheduling and slab fabrication after template. We set up a temporary counter with a microwave and a refrigerator elsewhere in the house so you can still feed yourselves.

    Tell Us What You Cook When the House Is Full

    Ventilation is sized to real cooking, so the useful conversation starts with your menu. Wok stir fry, steaks seared in cast iron, a pot of something simmering for four hours while people talk around the island. Call, tell us how you entertain, and we will come look at the ceiling, the panel and the path to the outside before anyone talks about cabinet colors.
